![DVB-S/S2 4K IRD]( "DVB-S/S2 4K IRD")
DVB-S/S2 4K Integrated Receiver Decoder—— YUK2300-4K —— Overview YUK2300-4K integrated receiver and decoder supports H.265 H.264 MPEG-2 AVS+ AVS2 video decoding. It supports RF ASI IP input, 1xHDMI/1x12G-SDI/4x3G-SDI/1xanalog stereo/1xAES/EBU output, it supports 2160P/1080P/ 1080I/720P/576I/480I multiple resolutions and supports DRA/AC3/EAC3/AAC/MPEG-1 and other audios. It supports two CAM cards to descramble different signals and support BISS-1 and BISS-E decryption. Product Features l Support multiple input RF IP ASIl RF input: DVB-S/S2, DVB-S2X(optional)l Multiple output: 1xHDMI/1x12G-SDI/4x3G-SDI/1xanalog stereo/1xAES/EBU/ASI/IP l Support H.265 H.264 MPEG-2 AVS+ AVS2 decodingl Support DRA AAC MPEG EAC3 AC3 passthroughl Demodulator + descrambler +re-mux+ decoder in one devicel IP (4×MPTS & 64×SPTS) output over UDP and RTP, support unicast multicast l Support SRT RTMP RTSP HTTP HLS(M3U8) IP protocol inputl 2 ASI input, 2 ASI independent output l Two independent CAM cards, descrambling two different signals with multi programsl CI descrambling supports NDS, Irdeto and other conditional access systems. Adopt unique digital decoding technology and dual PCMCIA interface, receive various encrypted satellite cable terrestrial digital TV signals by replacing different PCMCIA modules.l Support BISS-1, BISS-E decryption, support T2-MI de-encapsulationl Compatible with HD SD signalsl Support SDR/HDR10/HLGl Sampling rate support 4:2:2 and 4:2:0 Specification RF Input(DVB-S/S2) InputInput Frequency1×RF input, 1×RF loop, 75Ω950~2150MHzStandardHalf SyQuest Baseband filler(Roll off factor)DVB-S compliant0.35 for DVB-SDVB-S2 compliant0.15 to 0.35 for DVB-S2VCM and ACM supportedLNB Power SupplyFEC13V/18V/turn off, 22KHzll ratios compatible with standardsSupported Code RateMaximum Symbol Rate(DVB-S)DVB-S:Symbol rates: 1-54MSpsQPSK: 1/2, 2/3, 3/4, 4/5, 5/6, 7/8Maximum Symbol Rate (DVB-S2/S2X)DVB-S2:Normal(64800 bits) FECFRAME Symbol Rates:QPSK: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6QPSK 1-60MSps 8/9, 9/10 8PSK 1-60MSps8PSK: 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/1016APSK 1-58MSps16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/1032APSK 1-55MSps32APSK: 3/4, 4/5, 5/6, 8/9, 9/10 ASI Input/Output TS Over IP ASI input connector: 2×BNC, 75ΩConnector:1×RJ45, 10/100/1000 Base-TASI output connector: 2×BNC , 75ΩEffective bitrate: 600Mb/sExecutive standard: DVB-ASI, EN50083-9Frame length: (1-7)×188 adjustable bytesOutput bitrate ≤100Mb/sTransfer protocol: UDP/RTP, support unicast multicastSRT RTMP RTSP HTTP HLS(M3U8) Video Decoding Audio Decoding Video decoding format: H.265 HEVC/MPEG4 AVC/Audio decoding format: MPEG-1 layer I/II, MPEG-2 layer II, MPEG-2 AAC,H.264 AVC/MPEG-2/AVS+/AVS2MPEG-4 AAC LC 2-CHANNEL/5.1 CHANNEL AC3/DRA/EAC3Bitrate control: VBR CBR optionalBitrate: 64/128/256/384KbpsSampling Frequency: 48/44.1/32KHzSupport volume adjustmentSupport SDI embedded audio 12G/3G/HD/SD-SDI Output HDMI Output Connector: Connector:1xHDMI 1.4/2.0 HDMI type A12G-SDI: 1xBNCAudio: 1-ch analog stereo L & R audio (2x small XLR), 3G-SDI: 4xBNC1-ch AES/EBU(1x small XLR)HD-SDI output: SMPTE 292M, 1.485 Gbit/s (20bit)Resolution:2160p25/p30/p50/p60/1080p25/p30/p50/Output level: 800mV+-20 p-pp59.94/i50/i59.94/720p50/p59.94/576I/480IResolution:2160p25/p30/p50/p60/1080p25/p30/p50/p59.94/i50/i59.94/720p50/p59.94/576I/480I Audio Output Local and Remote Management Connector: 1-ch analog stereo audio and 1-ch AES/EBUConnector: 1×RJ45, 1000 Base-TAudio output mode: Left, Right, Dual Mono, StereoRemote control: HTTP WebLocal control: HTTP Web Equipment upgrade: IP Physical Specifications Dimension(L×W×H): 610mmx530mmx150mm, 19’’ 1U rackWeight: net weight 8.0KGPower: AC 90V～250V, 50/60HzPower consumption: 24W (excluding LNB power supply)Temperature range: 0 ~ 45°C(operation), -10 ~ 60°C(storage)Humidity: 10 ~ 90% (non-condensing)
会员价：
￥
0
RMB
市场价：
￥
0
RMB
发布时间：
2025
-
06
-
09
-
![Modular Type 3G-SDI distributor]( "Modular Type 3G-SDI distributor")
Modular Type 3G-SDI distributor—— YUK700-506 ——1U chassis2U chassis Overview YUK700-506 series is a modular-type 3G-SDI distributor. The platform adopts a modular card design. 1U chassis supports up to six 3G-SDI 1x4 distribution. 2U chassis supports up to twelve 3G-SDI 1x4 distribution Product Features l Support 3G-SDI, HD-SDI, SD-SDI, DVB-ASI signal, SMPTE 259M, SMPTE 292M format signal, and digital signals with bit rate between 10Mbps and 1.485Gbpsl Each module supports one 1*4 distributionl 1U chassis supports 6 modules, 2U chassis support 12 modulesl Support power off pass through. If the power is off, one of the SDI OUT1(SDI OUT1 next to the SDI IN1) can still output SDI input (IN1) normallyl Support cable equalization and clock recovery Specification Input Signal Format: 3G-SDI, HD-SDI, SD-SDI, DVB-ASIReturn Loss: 15dB@2970Mbps, 15dB@1485MbpsInput Automatic Cable Equalization: 250m@270Mbps (Equivalent Belden1694A cable) 100m@1485Mbps (Equivalent Belden1694A cable)Impedance: 75ΩConnector: BNC Output Signal Format: 3G-SDI, HD-SDI, SD-SDI, DVB-ASIImpedance: 75ΩConnector: BNCAmplitude: 800mVp-p±10% Index Shaking: ＜0.2UIOvershoot: ＜10% rangeRise/fall Time:Power Consumption: 4W Operation Environment Operation Temperature: 0 ~ +55℃Power: AC 110~260V 50Hz/60HzRelative Humidity: 10% ~ 90%Dimension: 19’’ 1U rack 482×370×44(mm), 19’’ 2U rack 482×370×88(mm)
会员价：
￥
0
RMB
市场价：
￥
0
RMB
发布时间：
2024
-
02
-
01
-
![Multi-channel video IRD]( "Multi-channel video IRD")
Multi-channel video IRD —— YUK700 ——Product Feature❖ Each device can be inserted 6 modules, coding, decoding, multiplexing, adaptation, modulation, transmission,splitter, satellite receiving and cable receiving are optional ❖ Support program multiplexing output and modulated RF signal output ❖ Support ASI input/output, SDI output can choose any input and output function❖ Gigabit IP input/output and SFP fiber output❖ Support HD input and SD output(with down-transformation function)❖ Support logo superposition and signal generator automatic output❖ IP input support RTP or UDP, support 8 MPTS and 64 SPTS input❖ IP output support RTP or UDP, support 8 MPTS and 64 SPTS output❖ Local monitoring: button and LCD display❖ Remote control: TCP/IP, XML❖ Suppport power cut memory function❖ Standard 1U rack (485mm×450mm×44mm)❖ Plug in card, dual power supply, buzzer alarmModule Option2-ch HD/SD Video Encoder Module 2-ch Audio Encoder Module ❖Input: 2 x HD/SD-SDI, 2 x HDMI ❖Video input format: NTSC/PAL adaptive ❖Input resolution: 1080I@50/59.94/60 720P@50/59.94/60, 576I/50 480I/60❖Encoding format: MPEG-2 H.264 optional❖Output bitrate: VBR, CBR❖Video bitrate: HD 8-20M, SD 2-15M❖Audio input：SDI HDMI embedded audio❖Encoding rate：64K to 384K❖Each module support 2 channel encoding❖Input: 2×analog stereo,2×AES/EBU ❖Audio encoding format: MPEG-1 Layer II, AAC-HE, AAC-LC ❖Sampling frequency: 48KHz❖Audio interface: small XLR❖Audio bitrate: 64 to 384K❖Each module support 2 channel encodingDVB-C/T/T2 ISDBT ATSC Receiver ModuleDVB-S/S2/S2X Receiver Module❖Input: 2×RF input❖Support 2 channel DVB-C/T/T2 ISDBT ATSC input❖Support 2 sets CAM cards to descramble the signal❖Support BISS-1 and BISS-E decryption❖Input: 2×RF input❖Support 2 channel DVB-S/S2/S2X input❖Support 2 sets CAM cards to descramble the signal❖Support BISS-1 and BISS-E decryption1-ch Video Decoder Module2-ch Audio Decoder Module❖Output: 1×HD-SDI, 1×HD-SDI (mirror),1×HDMI, 1×analog stereo or digital audio❖Decoding format: H.265, H.264, MPEG2,AVS2, AVS+❖Each module support 1 channel decoding ❖Output: 2×analog stereo and 2×AES/EBU❖Audio decoding format: MPEG-1 Layer II, AAC-HE, AAC-LC❖AES/EBU: 3-pin small XLR connector❖Analog stereo: 5-pin small XLR connector Modulator ModuleLive Streaming Decoder Module❖Support 1×ASI input , 2×ASI loop out and 1×RF output❖Support DVBC, DVBT, DMBT❖Support 16/32/64/128/256/64B/256B QAM❖Each Module support modulation of four adjacent channels ❖Output level: 120dBμV❖Support stream re-multiplexing❖Support PSI/SI automatic or manual insert edit function(PAT, PMT, CAT, NIT, SDT/BAT information sheet)❖Program, PID filtering and re-image❖Support IP input❖Multiple output, HDMI SD/HD-SDI AES/EBU analog stereo❖Support H.265 H.264 MPEG2 AVS+ decoding❖Support RTMP RTSP HLS HTTP SRT❖Support DRA AC3 EAC3 AAC MPEG❖Compatible with HD/SD signals Multiplexer Module4x1 Splitter Module❖Input: 3×ASI, BNC 75Ω❖Output: 2×independent ASI , BNC 75Ω❖Single ASI bitrate: 0 to 200MPS❖Support 1×12G/3G/HD/SD-SDI ASI input❖Support 4×12G/3G/HD/SD-SDI ASI output❖If the power is off, one of the SDI OUT1 can still output SDI input (IN1) normallySDI Fiber Converter Module(Bi-directional)SDI Fiber Converter Module(Uni-Unidirectional)❖Support 1 channel 12G 3G HD SD-SDI, ASI bi-directional transmission over single fiber❖Input: SDI/ASI adaptive ❖Fiber: single mode single fiber❖Fiber connector: LC/PC (standard)❖Transmission distance: 0-100km optional❖Support 2 channel 12G 3G HD SD-SDI, ASI uni-directional transmission over single fiber❖Input: SDI/ASI adaptive ❖Fiber: single mode single fiber❖Fiber connector: LC/PC (standard)❖Transmission distance: 0-100km optional
会员价：
￥
0
RMB
市场价：
￥
0
RMB
发布时间：
2019
-
06
-
04
-
![2-ch 4-ch H.264 Video Encoder]( "2-ch 4-ch H.264 Video Encoder")
2-ch 4-ch H.264 Video Encoder—— YUK2000 ——YUK2000-2YUK2000-4 Overview YUK2000 series HD/SD encoder is a multi-channel broadcast level professional H.264 MPEG-2 encoder.It supports maximum 4 channel HD/SD-SDI HDMI signal input, 2 channel ASI input, 2 channel ASI output and 1 channel Gigabit IP input output. It’s widely used for High Definition and Standard Definition simultaneous broadcasting for TV channel. Product Features l Support video: 2 channel or 4 channel HD/SD-SDI/HDMI inputl Support audio: HD/SD-SDI embedded audio, HDMI embedded audiol Support video encoding format: H.264 MPEG-2l Support audio encoding format: MPEG-1 LayerII, AAC-HE, AAC-LCl Support VBR and CBR encoding model IP output: output multicast unicast IP stream after multiplexing, IP transport protocol UDP RTPl 2 ASI input, 2 ASI independent output l Support mux re-mux and demux functionl Support High Definition input, Standard Definition program output (with down conversion function)l Support multiple resolutions of 1080I/720P/576I/480Il Support PID remapping, PCR correctionl Support low latency encoding l Support LCD display/key operationl Plug-in two power supplies, support buzzer alarm Specification Basic Information Video Encoding 4×HD/SD-SDI(BNC) input Encoding format:H.264 MPEG-24×HDMI inputBitrate:512Kbps-20Mbps, 4:2:0 8bit2×ASI(BNC) inputBitrate control: VBR CBR optional2×ASI(BNC) outputResolution:1080p30/p25/i60/i50 720p60/p50 576I 480I1×Gigabit IP (RJ45) output (also can be used as IP input)GOP structure: IBBP/IBP optional Audio Encoding TS Over IP Encoding format: MPEG1 LayerII AACProtocol: UDP RTPBitrate: 64/128/256/384KbpsTS over IP output can be turned on and offSampling frequency: 48/44.1/32KHzSupport unicast, multicast modeSupport volume adjustmentThe number of TS packets contained in UDP packets can be adjusted from 1 to 7Support SDI/HDMI embedded audio Stream Output DVB-ASI Serial Data Input Support ASI and IP simultaneous output Connector: BNC, 75ΩSDT parameters can be modifiedData pattern: Byte, Burst adaptiveStream fluctuation can be controlled by turn on or turn off empty packetsPackage length : 188, 204 adaptiveSupport UDP, RTP protocol DVB-ASI Serial Data Output Physical Specifications Connector: BNC, 75ΩTemperature range: 0~+40°C (operation), -20°C~+70°C (storage)Data transfer Rate: 270Mb/sPower: AC 90~260V, 50Hz/60Hz, redundant two power suppliesData pattern: ByteHumidity: ＜85%Package length: 188, 204 optionalDimension(L×W×H):485×350×44(mm) (19 inches 1U rack)Signal level: 800mV±80mVNet Weight: 6.2KG
会员价：
￥
0
RMB
市场价：
￥
0
RMB
发布时间：
2019
-
07
-
01
